Geofthall, Vicarage Farm – 3D CAD Services Project

At Imagine Draughting Services, we recently completed a 3D CAD Services project for Geofthall, Vicarage Farm, where the primary objective was to accurately recreate 3D models from existing technical drawings.

Project Overview

The client required detailed 3D CAD models, as the original CAD files were no longer available. Using the supplied technical drawings, our team carefully rebuilt the geometry in 3D, ensuring every detail reflected the original products as accurately as possible.

Given the complexity of the geometry and the technical requirements of the project, close collaboration was essential. We liaised directly with the client throughout the process to clarify details, validate dimensions, and ensure the final models met both functional and visual expectations.

Our Approach

• Conversion of legacy technical drawings into accurate 3D CAD models
• Close client communication to confirm technical details
• Careful attention to complex geometry and design intent
• Reliable, production-ready 3D outputs

This structured and collaborative approach ensured that the final 3D models were a true representation of the original products, despite the absence of original CAD data.

Need 3D CAD Conversion Support?

If you have a project that requires CAD conversion from drawings into 3D models, Imagine Draughting Services can help. We provide precise, dependable CAD solutions tailored to your technical requirements.
